Good image quality
The IPLEX RX and RT feature good image quality of our videoscopes. Our unique PulsarPic image processor reduces noise and sharpens images, resulting in the exceptionally high resolution image.
The IPLEX RX and RT faithfully and brightly reproduce very small defects, and the sharp and clear images enable accurate and reliable inspections.
Brighter Illumination System
The IPLEX RX and RT feature a new LED illumination system that is approximately twice as bright as conventional videoscopes, while dynamically adjusting light output to reduce halation when metal or reflective surfaces are inspected.
The PulsarPic image processor interacts intelligently with our illumination system to deliver an optimized amount of light and gain enhancement to provide images that are very clear and sharply defined.
Still Images and Movies as Crisp as Live Images
The IPLEX RX and RT can record inspected images to a removable USB flash drive as JPEG still images and MPEG4 movies.
The improved image quality of recorded images and movies enables accurate image diagnosis not only in the field but also at the office with the use of our free image management software, InHelp viewer.
Large Monitor Providing Easy Yet Accurate Inspections
The compact IPLEX RX and RT are equipped with a 6.5 in. monitor. The large monitor displays small defects clearly from a comfortable distance for inspectors for easy identification.
Optimized Image Gradation
The IPLEX RX features our unique image processing capability, WiDER, which brings out the darkest areas of an image without washing out the details of the brighter regions. The innovative technology provides optimum inspections of large areas or even highly reflective areas.
In addition, the IPLEX RX is equipped with sharpness and color adjustment functions to create optimal images depending on objects and applications.
Operation With Ease for All Remote Visual Applications
Compact and Portable Design
The IPLEX RX and RT weigh just 2.9 kg/ 6.4 lb including the two-hour operating Li-ion battery. The compact and portable design allows you not only to easily ship or transport the IPLEX RX and RT to inspection sites but to smoothly carry them to difficult-to-access locations.
Comfortable Inspections in Optimal Styles
The versatile design of the IPLEX RX and RT offers comfortable use to almost anyone. The pivoting handle of the monitor can change into a stand during inspections, and allows you to place the videoscope wherever you want to optimize viewing distance and angles. The video output capability of the IPLEX RX and RT enables inspections in a group or from remote locations by connecting the external monitor. Furthermore, the IPLEX RX and RT can be used while being carried with a shoulder belt or connected onto a tripod.
Smooth and Accurate Approach to a Target
The innovative articulation technologies equipped on the IPLEX RX and RT allow for smooth and accurate approaches to the most demanding inspection paths.
The improved TrueFeel articulation controller features precise and quick scope tip articulation by just light-touch operation, achieving smooth navigation through intricate paths.
The insertion tube is designed with the unique Tapered Flex to optimize both the scope stiffness and flexibility for excellent scope maneuverability.
Quick and Easy Operation
The most common operations such as scope articulation, image adjustment and recording can be easily activated by pressing dedicated Quick Access keys on the lightweight handset. The menu setting of the IPLEX RX and RT is simplified for easy and quick operation.
User-friendly Menu Icons
All menus of the IPLEX RX and RT are displayed with easy-to-understand icons. An inspector can intuitively recognize the menus and efficiently operate the desired feature or setting.
Rugged and Durable for Reliable Performance Even in Harsh Environments
The IPLEX RX and RT pass the impact tests including vibration and drop from a height of 1.2 m/ 3.9 ft. The tough system compliant with Military Standards withstands rough treatment and ensures reliable operation in difficult environments.
Operable in All Weather
The IPLEX RX and RT comply with internationally recognized Military Standards (MIL-STD-810F and MIL-STD-461F)* as well as IP55, passing a range of severe environmental tests, such as blowing rain/dust, high humidity, and icing rain. In addition, the daylight view monitor featuring low-reflection displays clear images even under bright sunlight.
*Reference specification page for MIL-STD compliance details
High-durability Insertion Tube
Operators are often required to inspect objects inside narrow paths with rough or sharp surfaces. The insertion tube of the IPLEX RX and RT has a crush and abrasion-proof design and is covered with a tough, special processed tungsten braid.
In addition, the IPLEX RX insertion tube features high temperature resistant up to 100C/212F. A high temperature sensor beeps and display visual warning to prevent overheating.
